4-Leg (Four Point)
4-Leg (Four Leg) Wire Rope Sling
Four leg (4-leg) wire rope slings provide maximum stability for lifting heavy and bulky loads. The four-point attachment system ensures even weight distribution and prevents load rotation during lifting. Ideal for large containers, machinery, and construction elements.
Four leg maximum stability configuration
Prevents load rotation
Even weight distribution
Master link assembly
Usha Martin wire rope
Working Load Limit (WLL) Chart
| Size | Working Load Limit |
|---|---|
| 6mm x 4 | 2.0T |
| 8mm x 4 | 3.6T |
| 10mm x 4 | 5.6T |
| 12mm x 4 | 8.0T |
| 14mm x 4 | 10.8T |
| 16mm x 4 | 14.0T |
| 18mm x 4 | 17.6T |
| 20mm x 4 | 21.6T |
| 22mm x 4 | 26.0T |
| 24mm x 4 | 30.8T |
| 26mm x 4 | 36.0T |
| 28mm x 4 | 41.6T |
| 32mm x 4 | 54.0T |
WLL shown is for vertical lift. Reduce capacity for angled lifts.
Technical Specifications
| Configuration | 4-Leg Assembly |
| Rope Diameter | 6mm to 32mm per leg |
| Working Load Limit | 2.0T to 50T |
| Spread Angle | 45° to 60° per leg |
| Construction | 6x19, 6x36 |
| Core | FC / IWRC |
| Master Link | Oblong Master Link |
| Bottom Fittings | Hook, Eye, Shackle |
